Thorlabs to show manual translation stages at SPIE Photonics West 2018

The XR Series manual translation stages feature crossed-roller bearings and a full aluminum body.

Content Dam Lfw Online Articles 2018 01 Xyz Translation Stage 25mm A3 780 002

The XR Series manual translation stages feature crossed-roller bearings and a full aluminum body for precision motion, high load capacity, and low angular deviation. Rear- and side-actuated versions and components are available to have left- or right-handed X, XY, XZ, YZ, and XYZ configurations. A dovetail feature is incorporated into the design for stacking stages and attaching the available component mounting carriers. The dovetail also allows for coarse positional alignment. The stages offer 25 or 50 mm translation with metric micrometers, <150 µrad of angular deviation in pitch and yaw, and at least 170 lbs horizontal load capacity.

SPIE Photonics West booth number: 807

To Learn More:

Contact:Thorlabs

Headquarters: Newton, NJ

Product: XR Series manual translation stages

Key Feature: 25 or 50 mm translation with metric micrometers

What Thorlabs says:

View more information on the XR Series manual translation stages.
