Displacement sensor from Lion Precision available with probe choices

July 19, 2010
The ECL101 Eddy-Current displacement sensor is CE compliant. The linear output sensor is available with a choice of probes with measurement ranges from 0.5 to 15 mm.

The ECL101 Eddy-Current displacement sensor is CE compliant. The linear output sensor is available with a choice of probes with measurement ranges from 0.5 to 15 mm. It has resolution of 0.004 to 0.06% of range, nonlinearity of ±0.5% of range, and temperature drift of probe at midrange of ±0.04% of range/°C.
Lion Precision
St. Paul, MN
[email protected]

-----

PRESS RELEASE

Mark Kretschmar
Lion Precision
Communication Manager
651-484-6544, fax 651-484-6824
[email protected]

High-Performance Eddy Current Sensor Offers Improved Displacement Measurements

St. Paul, MN USA, January 19, 2010

The ECL101 Eddy-Current displacement sensor is an improved, CE compliant version of Lion Precision’s original ECL100 sensor. The ECL101 noncontact sensor offers improvements in immunity to electromagnetic interference (EMI) and thermal stability as well as lower power consumption. The linear output sensor is available with a selection of probes offering measurement ranges from 0.5mm to 15mm, and features a unique front panel range indicator to alert the operator to out-of-range conditions. The sensor has applications in any industry requiring precision noncontact displacement measurement, especially in a hostile environment involving fluids or debris in the measurement area.

ECL101 Specifications

Resolution: 0.004% - 0.06% of range

Nonlinearity: ±0.50% of range.

Temperature Drift of Probe at mid-range: ±0.04% of range/°C

Outputs: 0-10VDC, 0-20mA

Input Power: 12-24VDC

More detailed information is available at www.eddycurrentsensors.com or www.lionprecision.com.
