BEI Kimco actuator to position spectrometer analyzing asteroid Bennu

Sept. 28, 2016
BEI Kimco designed a voice coil actuator for the OSIRIS-Rex spectrometer that will sample asteroid Bennu in 2018.

IMAGE: BEI Kimco's moving magnet voice coil actuator (VCA) will position the spectrometer on the Origins-Spectral Interpretation Resource Identification Security Regolith Explorer (OSIRIS-Rex) spacecraft that will rendezvous with asteroid Bennu in 2018 and return samples to Earth in 2023. (Image credit: BEI Kimco)

Sensata Technologies brand company BEI Kimco (Vista, CA) is a part of NASA's first asteroid sampling mission that could revolutionize understanding of the early solar system. BEI Kimco designed a customized Moving Magnet Voice Coil Actuator (VCA) to meet the harsh requirements for a spectrometer moving mirror application on the Origins-Spectral Interpretation Resource Identification Security Regolith Explorer (OSIRIS-Rex) spacecraft. The OSIRIS-Rex launched on Sept 8, 2016 from Cape Canaveral Air Force Station in its mission to rendezvous with the asteroid named Bennu in 2018 and return samples to Earth in 2023.

RELATED ARTICLE: Instruments trace the history of Eros

For this space mission, a customized BEI Kimco moving magnet VCA was attached to, and will position the moving mirror assembly of the OSIRIS-Rex Thermal Emission Spectrometer (OTES). As the spacecraft approaches Bennu, the spectrometer scans the surface so that the material can be analyzed for different parameters. OSIRIS-REx will spend two years surveying the asteroid in unprecedented detail. Then, in a robotic first, the spacecraft will reach out its mechanical arm and take a sample from the asteroid. Though the sample will be small--only a couple of pounds at most--it will be a time capsule of sorts recording our solar system's creation. With the sample stored safely, the spacecraft will speed away from the asteroid on a path back to Earth.

The BEI Kimco VCA was manufactured to custom requirements for high reliability and fail-safe operation. Redundant technology, low-outgassing and high precision for exact motion control positioning were all key requirements to the actuator design. It was also critical to stay within the specific size, weight, and power limits. This was achieved in a housing measuring approximately 2 inches in diameter by 3 inches long. To meet the requirements for near-zero emissions, BEI Kimco developed the actuator minimizing the use of adhesives or inks and using only approved materials with no outgassing and incorporating neodymium iron boron (NeFeB) magnets for high operating efficiencies.

In recognition of the team that worked on the OTES project, a signature plaque including individuals as well as BEI Kimco and other other suppliers, was attached to OTES before it left earth. An identical plaque was presented to BEI Kimco and each company or person included on the plaque.

"The [asteroid Bennu] sampling mission was another exciting opportunity for us to meet unique customer demands," says Jim McNamara, senior applications engineer. "In this case, a customized low outgassing design with high reliability, built-in redundancies, strict quality control, and cleanliness were all needed. It will be interesting to see the results of the mission in 2023 when the samples are brought to earth."

For more information on OSIRIS-Rex, see
