Developer of motors and control systems, Nanotec Electronic US Inc. (Medford, MA), is introducing the NOE1, the first rotary encoder in a new product series of optical encoders. Due to its compact size, it is ideal for applications that require accurate positioning and use small stepper or BLDC motors. Applications in medical technology, such as microscopy and micro-imaging, and other fields require that they have small sizes. In response, Nanotec developed a rotary encoder that fits small stepper and BLDC motors with its compact dimensions of 20x26x10 mm. This encoder is ideal for use when high-resolution positioning is required.
-----
PRESS RELEASE
Optical mini-encoder NOE1 for compact applications
High-precision position measurement for small BLDC and stepper motors
Medford, MA, July 26, 2012 – Medford-based Nanotec Electronic US Inc. is introducing the NOE1, the first rotary encoder in a new product series of optical encoders. Due to its compact size, it is ideal for applications that require accurate positioning and use small stepper or BLDC motors.
In addition to the motor and a good controller, the rotary encoder is an essential component when accurate, high-resolution positioning is called for. Applications in medical technology and other fields require that they have small sizes. In response, drive specialist Nanotec developed the optical 3-channel encoder NOE1, a rotary encoder that fits small stepper and BLDC motors with its compact dimensions of just 20x26x10 mm. Optical encoders measure using photodiodes that read off a code disk. The resolution of the NOE1 is 2000 pulses per revolution. Quadrature increases the resolution to 8000 increments per revolution, which corresponds to 40 increments per 1,8° step for a stepper motor. This makes it possible to measure the commutation angle in field-oriented control operation and enables operation with very good synchronization, even at slow speeds. The line driver for higher interference immunity is already integrated into the small housing.
For BLDC motors, the NOE1 is ideal for use when high-resolution positioning is required. For stepper motors, the NOE1, in conjunction with our closed loop controls delivering performance Beyond MicroStepping (field-oriented control with sine commutation) opens up new fields of application in areas where precision positioning with high torque is required.
About Nanotec
Nanotec Electronic, U.S., Inc. is a subsidiary of Nanotec Electronic GmbH & Co. KG, Feldkirchen, one of the leading manufacturers of motors and control systems for high-quality drive solutions in Germany. Active on the market since 1991, Nanotec Electronic GmbH & Co. KG offers a comprehensive product line distinguished by well thought-out design and strict quality control. Certification in accordance with the newest ISO 9001:2008 standard from TÜV Management Service is a testament to this quality. In addition to standard motors and power electronics, Nanotec offers customized versions with relatively short production runs and develops optimal, individualized solutions with its engineers. Thanks to assembly at the corporate headquarters in Feldkirchen and large warehousing capacity, Nanotec is capable of quickly and flexibly reacting to customer requests. Nanotec has subsidiaries in Changzhou, China and Medford, MA, USA.
-----
