Test facilities evaluate short-range 3-D imaging

This summer, a consensus-based standards-development process for 3-D imaging devices will begin.

Th 0606lfwnwsbks1

This summer, a consensus-based standards-development process for 3-D imaging devices will begin. Such devices are becoming important measuring tools in the manufacturing, construction, and transportation sectors; numerous models, capable of digitally imaging objects from as small as pipe fittings to as large as an entire bridge, are on the market. A lack of standard tests to verify manufacturers’ performance specifications is inhibiting wider market acceptance of these devices, however.

Th 0606lfwnwsbks1
Click here to enlarge image

In response, researchers at the National Institute of Standards and Technology (NIST; Gaithersburg, MD) recently established an indoor artifact-based facility to create new test protocols and performance measures to evaluate such 3-D-imaging systems. Several prototype artifacts (for example, spheres, a stairway, and a slotted disc) are currently being tested for evaluating both instruments and software. The new facility is part of a larger effort to provide standard test protocols and associated facilities for evaluating and calibrating these instruments. In addition to the artifact-based facility, NIST also operates an indoor calibration facility with a 60 m range and is developing a separate 3-D facility so that manufacturers or research groups can send in instruments for spatial calibrations. Finally, NIST will establish an outdoor ranging facility for evaluating the performance of 3-D imaging systems up to 150 to 200 m. Contact Steven Phillips at [email protected].
