Short- and mid-wavelength infrared nanowire photodiodes are uncooled

Nanowires of InAs and InAsSb on an indium phosphide (InP) substrate form room-temperature SWIR or MWIR photodiodes suitable for focal-plane arrays.

Images of Utah's Salt Lake Valley captured in visible light (left) and shortwave infrared (SWIR; right) illustrate how SWIR imaging can cut through haze.
Images of Utah's Salt Lake Valley captured in visible light (left) and shortwave infrared (SWIR; right) illustrate how SWIR imaging can cut through haze.
Sensors Unlimited

Shortwave- and midwave-infrared (SWIR and MWIR) sensors, including focal-plane arrays (FPAs), are what enable many essential infrared sensing and imaging applications (see figure), from military (locating missiles from the heat they produce) and science (remote sensing, spectroscopy) to environmental (gas monitoring, seeing through haze). However, existing practical SWIR and MWIR sensors all suffer from a significant flaw -- they require cooling. This includes sensors based on indium antimonide (InSb), mercury cadmium telluride (MCT), and indium arsenide / gallium antimonide (InAs/GaSb) type-II superlattice FPAs. The need for a cooling system adds bulk, especially to very small photodetecting systems, and raises both cost and need for maintenance.

A new approach by researchers from the University of California, Los Angeles and Cardiff University (Cardiff, Wales) solves this problem.1, 2, 3 The room-temperature uncooled SWIR and MWIR detectors created by the scientists consists of arrays of vertically oriented nanowires of InAs or InAsSb fabricated on an indium phosphide (InP) substrate so that the junction of the wires with the substrate creates InAs-InP heterojunctions. The structure can then be passivated with a layer of aluminum oxide (Al2O3), which lowers the nonradiative recombination at the nanowire surfaces.

Computer simulation showed that, in comparison to a planar uncooled InAs photodiode, an uncooled InAs(Sb)-InP nanowire heterojunction photodiode had a plasmonic mode resonance peak D* of 3.5 x 1010 cm Hz1/2 W−1 at a 3.0 μm wavelength -- on the order of ten times higher than the planar photodiode.

The researchers fabricated nanowire photodetectors based on a standard process that they had previously developed, growing the nanowires on patterns optimized for photodetection in the proper wavelength range, then passivating them with Al2O3. The passivation coating on the very tips of the nanowires was then removed. Using the nanowires themselves as shadow masks, gold was deposited on the nanowire-bearing surface, creating an array of nanoholes in the gold that form a plasmonic grating.  This grating is important: its job is to strengthen the coupling of incident light into the nanowires' tips via plasmonic resonances.

In an example, the fabricated active area of a SWIR device was 200 × 200 μm2. The detector surface contains nanowires with a 1300 nm pitch, 264 nm diameter, and 1650 nm height. The room-temperature spectral response for this device contains peaks at about 2.0 and 3.4 μm, corresponding to  plasmonic resonances.

This research was done by Dr. Dingkun Ren, Dr. Khalifa M. Azizur-Rahman, Prof. Diana L. Huffaker, and their co-workers.

REFERENCES:

1. Dingkun Ren et al., Nano Letters (2018); https://doi.org/10.1021/acs.nanolett.8b03775.

2. Dingkun Ren et al., Nanotechnology (2018); https://doi.org/10.1088/1361-6528/aaed5c.

3. Dingkun Ren et al., Nano Letters (2019); https://doi.org/10.1021/acs.nanolett.8b04420.
