Optical imaging catheter with metalenses could better detect diseases

July 31, 2018
Conventional optical elements in catheters are prone to aberrations that obstruct the full capabilities of optical imaging.

A team of researchers at Massachusetts General Hospital (MGH; Boston, MA) and the Harvard John A. Paulson School of Engineering and Applied Sciences (SEAS; Cambridge, MA) has developed endoscopic imaging catheters that overcome the limitations of current systems. The conventional optical elements in catheters used to access hard-to-reach areas of the body, such as the gastrointestinal tract and pulmonary airways, are prone to aberrations that obstruct the full capabilities of optical imaging.

Related: Novel OCT method shows differences underlying the airway responses of asthma patients

"Clinical adoption of many cutting-edge endoscopic microscopy modalities has been hampered due to the difficulty of designing miniature catheters that achieve the same image quality as bulky desktop microscopes," says Melissa Suter, an assistant professor of Medicine at MGH and Harvard Medical School (HMS) and co-senior author of the paper describing the work. "The use of nanooptic catheters that incorporate metalenses into their design will likely change the landscape of optical catheter design, resulting in a dramatic increase in the quality, resolution, and functionality of endoscopic microscopy. This will ultimately increase clinical utility by enabling more sophisticated assessment of cell and tissue microstructure in living patients."

"Metalenses based on flat optics are a game-changing new technology because the control of image distortions necessary for high-resolution imaging is straightforward compared to conventional optics, which requires multiple complex-shaped lenses," says Federico Capasso, the Robert L. Wallace Professor of Applied Physics and Vinton Hayes Senior Research Fellow in Electrical Engineering at SEAS and co-senior author of the paper. "I am confident that this will lead to a new class of optical systems and instruments with a broad range of applications in many areas of science and technology."

"The versatility and design flexibility of the nanooptic endoscope significantly elevates endoscopic imaging capabilities and will likely impact diagnostic imaging of internal organs," says Hamid Pahlevaninezhad, Instructor in Medicine at MGH and HMS and co-first author of the paper. "We demonstrated an example of such capabilities to achieve high-resolution imaging at greatly extended depth of focus."

To demonstrate the imaging quality of the nanooptic endoscope, the researchers imaged fruit flesh, swine and sheep airways, and human lung tissue. The research team showed that the nanooptic endoscope can image deep into the tissue with significantly higher resolution than provided by current imaging catheter designs.

The images captured by the nanooptic endoscope clearly show cellular structures in fruit flesh and tissue layers and fine glands in the bronchial mucosa of swine and sheep. In the human lung tissue, the researchers were able to clearly identify structures that correspond to fine, irregular glands indicating the presence of adenocarcinoma, the most prominent type of lung cancer.

"Currently, we are at the mercy of materials that we have no control over to design high-resolution lenses for imaging," says Yao-Wei Huang, a postdoctoral fellow at SEAS and co-first author of the paper. "The main advantage of the metalens is that we can design and tailor its specifications to overcome spherical aberrations and astigmatism and achieve very fine focus of the light. As a result, we achieve very high resolution with extended depth of field without the need for complex optical components."

Next, the researchers aim to explore other applications for the nanooptic endoscope, including a polarization-sensitive nanooptic endoscope, which could contrast between tissues that have highly organized structures, such as smooth muscle, collagen, and blood vessels.

Full details of the work appear in the journal Nature Photonics.
